Features
This is the only retractable screen system, which doesn’t use pleated screens, or cables that are able to cover such large spans. Vista View is the perfect solution for bi-fold doors, stacking doors, and any large opening. The unique advanced heat welded technology provides a super strong system which can resist winds up to 186 mph, as well as most accidental impacts. The zipper screen system uses a very low profile tracking system along with a streamline housing gives you the total solution for the perfect retractable screen for large openings. Vista View is available in 3 sizes… 60mm housing size was added to capture the French Door market and can cover most standard units with a SINGLE screen. The 70mm units cover most standard door systems up to 216″ wide, and the 80mm covers the rest up to 336″. In addition, a newly added fully accessible recessed model has been added to the 80mm version.
Advantages
The Vista View screen system has many advantages over any and all of our competitors, whether a flat roll screen or pleated. No other screen system can cover the huge openings that this system covers. By having the zipper screen captured edge we are able to market this system as “PET-FRIENDLY” as it will keep small animals contained, as well as holding up to very high winds with no damage. Unique to this system, we have the only patented “braking system” in our pull bar….. so where you let go is where the screen stops. Lastly, in some models, you have the option for both a standard rounded housing OR our new square housing.
Specifications
60MM — Max size 120″ high x 72″ wide single 120″ x 144′ Double
70MM — Max size 120″ high 108″ wide single 120″ x 216″ Double
80MM– Max size 132″ high x 168″ wide single 132″x x336″ Double
STANDARD COLORS– WHITE, BLACK, CLASSIC BRONZE, CLEAR ANODIZED (UPCHARGE)
STANDARD HARDWARE — BLACK, WHITE, GRAY STANDARD SCREEN MESH — CHARCOAL
